SINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617C

Product Categories
SINO VEHICLE & EQUIPMENT COMPANY LTD
Contact Now

SINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617C

Place of Origin : China

Brand Name : CIVL

Certification : ISO,CCC

Model Number : CIVL

MOQ : 1

Price : Negotiable

Packaging Details : Nude

Delivery Time : Within 35 days

Payment Terms : LC/TT etc, L/C, T/T

Supply Ability : 100 units per week

Cab : HW70/HW76

Engine : WD615.95E

Wheelbase (mm) : 1800+5600

Complete vehicle External dimension(L*W*H) mm : 10765*2498*3290

Laoding weight : 40t

Tyre : 12.00R20

Contact Now

SINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617C

Description:

  1. SINOTRUCK HOWO series trucks own the elegant appearance, strong operation system and excellent safety.
  2. Sino Heavy Machinery Co,Ltd is the authorized company of SINOTRUK(CNHTC), and mainly deal with heavy duty trucks /all spare parts and service We supply HOWO, , KING, GOLDEN PRINCE, HOHAN series 4X2, 6X4, and 8X4 dump trucks, tractor trucks, cargo trucks, garbage trucks, oil tank trucks, water tank trucks, log trailers tractors, terminal tractors, etc. Our products arrange from 190 horse power to 410 horse power, and loading capacity cover from 5 tons to 50 tons.

Respective vehicle Number ZZ1167M4617C

Cab

 Model HW70/HW76

Type

Extended Cab, single berth, up/down and front/

back adjustable steering wheel, VOD instrumented

control module, double locking safety belt, exterior

sun visor.

Engine

Model

 WD615.95E

Type

Six cylinders inline, two valve, supercharge intercooler,

supercharge postposition.

Displacement L

9.26
Maximum torque (Nm) 290

Clutch

430diaphragm spring clutch, Hydraulic control air

assisted

Transmission

SINOTRUK HW series 10 gears Transmission,

Transmission with main and auxiliary transmission

structure, main transmission with double counter shaft,

auxiliary transmission with planetary reduction.
Suspension

Front and rear leaf spring suspension, front suspension

with shock absorber, transverse stabilizer rear

suspension is disconnected type with transverse

stabilizer.
Steering system

ZF8098 steering gear, ZF steering oil pump, system

pressure 18Mpa

Braking system

 Service brake: dual circuit compressed air brake.

Parking brake(emergency brake): spring energy,

compressed air operating on rear wheels
Auxiliary brake: engine exhaust brake
Option: ABS
Electrical system

Voltage: 24V generator: 1540W battery: 12V/165Ah,

2 piece
Wheelbase (mm) 1800+5600
Front/rear suspension (m) 1.500/1.710
Gross Mass (kg) 50000
Curb weight(vehicle/chassis)kg 9720
Maximum loading capacity(kg) 40000
Complete vehicle External dimension(L*W*H) mm 10765*2498*3290
Body volume (mm): 8600*2300*1190

SINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617CSINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617CSINOTRUK HEAVY DUTY CARGO TRUCK , ARMY GREEN MAJESTY ZZ1167M4617C

We can supply different capacity and driving mode dump truck, for more in formations, kindly contact me !
Other Truck and trailer can be provide according to your request, freely contact me for the informations and quotations.
